| Brand Name: | Winsmart |
| Model Number: | SMTL460 |
| MOQ: | 1 set |
| Price: | USD1-150K/set |
| Packaging Details: | Plywood case |
| Payment Terms: | L/C, T/T, Western Union |
PCB Depaneler SMT Machines For Printed Circuit Board Laser Cutting
PCB Laser Cutting Machine Advantages:
1. The laser process is completely software-controlled. Varying materials or cutting contours are easily taken into account by adapting the processing parameters and laser paths. There is also no need to factor in retooling times during a change of production.
2. No appreciable mechanical or thermal stresses occur. The ablation products are extracted by suction directly at the cutting channel. Even sensitive substrates can thus be precisely processed.
3. The laser beam merely requires a few µm as a cutting channel. More components can thus be placed on a panel.
4. The system software differentiates between production and set up processes which drastically reduces instances of faulty operation.
PCB Laser Cutting Machine Specification:
| Laser | Q-Switched diode-pumped all solid-state UV laser |
| Laser Wavelength | 355nm |
| Laser Source | Optowave UV 15W@30KHz |
| Positioning Precision of Worktable of Linear Motor | ±2μm |
| Repetition Precision of Worktable of Linear Motor | ±1μm |
| Effective Working Field | 460mmx460mm(Customizable) |
| Scanning Speed | 2500mm/s (max) |
| Working field | 40mmх40mm |
PCB Laser Cutting Machine Working Principle:
PCB Laser Cutting Machine Workshop Display:
FAQ:
Q: What kind of PCBs are workable to use this machine?
A: FPC and FR4 panels, covering v score and tab boards.
Q: What is laser head of the machine?
A: We use USA Optowave laser.
Q: What kind of laser source you provide?
A: Green, CO2, UV and picosecond.
Q: What is cutting speed?
A: It depends on PCB material, thickness and cutting effect requirements.
Q: Does it cause dust during cutting?
A: No dust, but smoke, machine comes with exhaust system and water cooler
|
|
