Flexible PCB Board Cutting Machine FPC Punch With Cutomized Die Tooling
Features:
1. Depaneling PCB/FPC by means of punching dies, to avoid micro-cracks caused by manual.
2. Die toolings is changeable
3. Easy set up of punching dies
4. Loading and unloading PCBs is convenient
5. Easy operation, has safe protection system
6. Air cylinder driven
PCB Punching Machine Introduction:
Double switch start operation.
Device configuration mode and out of the chute,and out of the lower mold automatic pick and place convenient and safe products.
Emergency stop switch,identify problems and timely shutdown.
Security doors,installation and commissioning of the mold to avoid straying hands.(Normal operation with out security door doesnot work).
Safety pressure setting function,limit alarm.Automatic counting,limit down time.
The internal stress generated when the cutting board to a minimum and to avoid cracking of tin.
Suitable for high volume routed boards.
Advantages:
1. Pneumatic, environmental protection
2. High efficiency, suitable for high volume PCBs
3. Security door protection, ensure safe production
Specification:
| Working area | 460*320mm |
| Working pressure | 0.45-0.7Mpa |
| Cutting precision | ±0.05mm |
| Cycle time | 7-15 seconds |
| Output | 8T |
| PCB/FPC thickness | 0.08-3.5MM |
| PCB/FPC material | FPC, FR1, FR4, CEM-1, CEM-3, MCPCB |
| Cutting mode | Punching |
| Punch fixture | Die tooling(mold) |
| Working Property |
LCD display, Automatically records the number of processed products, automatic punching |
| Transmission port | International standard |
| Operation Language | English |
| Stroke | 50MM |
| Mold height | 170MM |
| Power | 380/220V |
| Fuse | 3A |
| Machine dimension | 820x740x1750mm |
| Machine weight | 680kgs |
PCB Punching Mold:
|
| Brand Name: | Winsamrt |
| Model Number: | SMTP300 |
| MOQ: | 1 set |
| Price: | USD1-10000/set |
| Packaging Details: | Plywood case |
| Payment Terms: | L/C, T/T, Western Union |
Flexible PCB Board Cutting Machine FPC Punch With Cutomized Die Tooling
Features:
1. Depaneling PCB/FPC by means of punching dies, to avoid micro-cracks caused by manual.
2. Die toolings is changeable
3. Easy set up of punching dies
4. Loading and unloading PCBs is convenient
5. Easy operation, has safe protection system
6. Air cylinder driven
PCB Punching Machine Introduction:
Double switch start operation.
Device configuration mode and out of the chute,and out of the lower mold automatic pick and place convenient and safe products.
Emergency stop switch,identify problems and timely shutdown.
Security doors,installation and commissioning of the mold to avoid straying hands.(Normal operation with out security door doesnot work).
Safety pressure setting function,limit alarm.Automatic counting,limit down time.
The internal stress generated when the cutting board to a minimum and to avoid cracking of tin.
Suitable for high volume routed boards.
Advantages:
1. Pneumatic, environmental protection
2. High efficiency, suitable for high volume PCBs
3. Security door protection, ensure safe production
Specification:
| Working area | 460*320mm |
| Working pressure | 0.45-0.7Mpa |
| Cutting precision | ±0.05mm |
| Cycle time | 7-15 seconds |
| Output | 8T |
| PCB/FPC thickness | 0.08-3.5MM |
| PCB/FPC material | FPC, FR1, FR4, CEM-1, CEM-3, MCPCB |
| Cutting mode | Punching |
| Punch fixture | Die tooling(mold) |
| Working Property |
LCD display, Automatically records the number of processed products, automatic punching |
| Transmission port | International standard |
| Operation Language | English |
| Stroke | 50MM |
| Mold height | 170MM |
| Power | 380/220V |
| Fuse | 3A |
| Machine dimension | 820x740x1750mm |
| Machine weight | 680kgs |
