| Brand Name: | Winsmart |
| Model Number: | SMTSR224 |
Automatic Soldering Robot Dual Heads Dual Tables Automatic SMD Soldering Machine
Overview:
Soldering Robot also be known as Automatic Soldering Machine, It is suitable for SMT soldering process in the posterior segment of temperature-sensitive electronic components soldering, and the soldering process for the heat-sensitive components which cannot be reflowed soldering .
Our soldering robot have various soldering modes, soldering process, effectively improve the quality of soldering process.
Robotic Soldering Machine Features:
Applicable for different products. Soldering temperature can be set as per actual need, (different temperature can be set for each solder joint)
The soldering iron unit can be multi-directionally adjusted, which can protect the PCB and components from damage.
Numerically controlled temperature ( static air condition : +/- 1C ).
With the handheld LCD Teaching Pendant , the programming is simple and easy to learn .
In the soldering process, the solder tip has rapid heat recovery and a long life span.
Robotic Soldering Machine Specifications:
| Model | SMTSR224 |
| Dimension | 680*500*720mm |
| Weight | 90Kg |
| Control | PLC |
| Programming | Teaching box |
| Driving mode | Stepper motor |
| Stroke | 500(X)x300(Y1)x300(Y2)x80(Z)x360(R) |
| Soldering head | 2 |
| Repeatability | ±0.02mm(X/Y/Z) |
| Temp. Range | 0-550℃ |
| Solder Wire Spec | ￠0.3-1.6mm |
| Number of axes | Multi |
| Working pressure | 0.4~0.6Mpa(No water mist) |
| Power | AC110V/220V 300W |
| Display | LCD |
Robotic Soldering Machine Application:
|
|
