| Brand Name: | Winsmart |
| Model Number: | SMTSR113 |
| MOQ: | 1 set |
| Price: | USD1-10000/Set |
| Packaging Details: | Plywood case |
| Payment Terms: | L/C, T/T, Western Union |
Single Table Single Head Soldering Robot Automatic SMD Soldering Machine
Robotic Soldering Machine Application:
Suitable for automotive electronics, digital, electronic, electro-acoustic, LCD, circuit board and other production industries, connectors, networks, transformers, cable, FPC / COF soldering, computer motherboards, CABLE, speakers and motors high quality soldering.
Robotic Soldering Machine Features:
1. With automatic smoke collection to keep the air clean (optional).
2. High-strength solder head can be customized for high quality melding.
3. Program can be fast made by re-set ,insert and delete the spot of the soldering or full modification.
4. Clamping slot for easily fetch and change the products.
5. Feeding tins at anytime to apply for multiple welding and high efficiency.
6. Weller soldering temperature controller, control the temperature more accurately and more durable.
7. Auto anti-collapse.
8. Programming with teaching pendant for all new users to operate within 2 hours.
9. Auto transport tape is optional for full automatic.
10. The mode of two users managements of different right for engineer and operator.
11. With functions of calibration of R axis, correction of wrong operations.
12. ±0.02mm repeated precision to achieve precised soldering.
Robotic Soldering Machine Specifications:
| Model | SMTSR113 |
| Dimension | 880*700*830mm |
| Weight | 70Kg |
| Control | PLC |
| Programming | Teaching box |
| Driving mode | Stepper motor |
| Stroke | 300(X)x300(Y)x80(Z) |
| Soldering head | 1 |
| Repeatability | ±0.02mm(X/Y/Z) |
| Temp. Range | 0-500℃ |
| Solder Wire Spec | ￠0.3-1.6mm |
| Number of axes | 3 |
| Working pressure | 0.4~0.6Mpa(No water mist) |
| Power | AC110V/220V 300W |
| Display | LCD |
Robotic Soldering Machine Soldering Cases:
Our Service:
1. Lifetime technical support and 2 years warranty.
2. Free replacement or refund would be done in case of any quality problem.
3. Fast response/feedback within 12 hours
4. Engineers are available to be sent to do oversea installation and training.
5. Solid packaging to prevent damage from transportation.
Shipment:
1. DHL/FedEx/UPS/TNT Express
2. Air
3. Railway
4. Ocean
5. Truck
|
|
