| Brand Name: | Winsmart |
| Model Number: | SMTSD221 |
| MOQ: | 1 set |
| Price: | USD1-10000/Set |
| Packaging Details: | Plywood case |
| Payment Terms: | L/C, T/T, Western Union |
Double Head Double Tables Vacuum Suction Type Robotic Screwdriver Machine
Robotic Screwdriver Machine Overview:
This equipment increases throughput on a variety of assembly applications.
This system is completely integrated and include robot, electric drivers, screw feeder systems.
The controller can store programs.
Robotic Screwdriver Machine Process
Compared to other manufacturing methods, automatic screw machining offers a number of advantages, including:
1. Automation: Automatic screw machines can run with little operator oversight. They generally only require assistance during setup and changeover.
2. Efficiency: 2 seconds per screw, increases efficiency of production.
3. Save money
Robotic Screwdriver Machine Features:
1. With intelligent detection function, it can detect leak lock, floating lock, sliding screws, etc.
2. High versatility, the replacement screw delivery module can be adapted to the M1.0-M5 screw lock
3. High flexibility, standard universal clamp for a variety of models of screw locks.
4. Dual platform design, automatic alternate operation without downtime, fast speed and high efficiency
5. 2G storage space, which can store thousands of screwdriving programs, each program supports 9999 screwdriving instructions
6. The utility model adopts the vacuum suction screw method, has good versatility, overcomes the feature that the wind blow screw can not send the length to diameter ratio of 1.2, and overcomes the characteristics that the magnetic suction screw can not take the stainless steel screw.
7. The display adopts 320*240 high-resolution color screen and full English operation interface, easy to learn and use.
Robotic Screwdriver Machine Specifications:
| Model | SMTSD221 |
| Moving range | 250X*300Y*100Zmm |
| Processing range | 200X*300Y*110Zmm |
| Repetitive accuracy | ±0.02mm(X/Y/Z) |
| Fixture platform | 2 |
| Screw head | 2 |
| Applicable screw | M1.0-M5.0 |
| Screw conveying method | Vacuum suction |
| Driving mode | precision stepping motor+precision lead rail |
| Axes of motion | 6 axes |
| Display mode | LCD |
| Control system | special controller for screwdriver machine |
| Program record capacity | 9999 |
| Programming interface | teaching pandent |
| Air pressure | 4~6kg cm2 |
| Vltage | AC220V |
| Dimensions | 800X500X725mm |
| Weight | 95kg |
Robotic Screwdriver Machine Applications:
The automatic screwdriver machine is suitable for automated assembly in the electronics industry such as cameras, mobile phones, hard disks, keyboards, printers, computers, DVDs, home appliances, toys, appliances, communication equipment, electronic processing and assembly,etc. Automobile industry assembly, such as automotive motors, parts assembly, etc.
Robotic Screwdriver Machine Suitable Screws:
|
|
