| Brand Name: | Winsmart |
| Model Number: | SMTSD112 |
| MOQ: | 1 set |
| Price: | USD1-10000/Set |
| Packaging Details: | Plywood case |
| Payment Terms: | L/C, T/T, Western Union |
Air Blowing Type Automatic Screw Dispenser Robotic Screwdriver Machine
Robotic Screwdriver Machine Types:
1. Vacuum suction
2. Air blowing
Robotic Screw Fastening System Process
Compared to other manufacturing methods, automatic screw machining offers a number of advantages, including:
1. Automation: Automatic screw machines can run with little operator oversight. They generally only require assistance during setup and changeover.
2. Efficiency: 2 seconds per screw, increases efficiency of production.
3. Save money
Robotic Screw Fastening System Features:
Desktop automatic tightening screw platform,Fully automated operation, save time, save labor, save costs, automatically tight screws.
Do not need to be equipped with an external computer, can do single operation, easy installation.
Versatility, replac the screw delivery module, suction nozzle, screw bit, it can be adapted to M1.0~ M4.0 screw.
At one product, the screw hole level can be different one the same side, it can do different.
Auto-sensing start function.
Robotic Screw Fastening System Specifications:
| Model | SMTSD112 |
| Moving range | 300X*300Y*100Zmm |
| Processing range | 270X*300Y*110Zmm |
| Repetitive accuracy | ±0.02mm(X/Y/Z) |
| Fixture platform | 1 |
| Screw head | 1 |
| Applicable screw | M1.0-M5.0 |
| Screw conveying method | Air blowing |
| Driving mode | precision stepping motor+precision lead rail |
| Axes of motion | 3 axes |
| Display mode | LCD |
| Control system | special controller for screwdriver machine |
| Program record capacity | 9999 |
| Programming interface | teaching pandent |
| Air pressure | 4~6kg cm2 |
| Vltage | AC220V |
| Dimensions | 680X500X725mm |
| Weight | 60kg |
Robotic Screw Fastening System Suitable Screws:
Robotic Screw Fastening System Package:
|
|
