| Brand Name: | Winsmart |
| Model Number: | SMTSD8101 |
| MOQ: | 1 set |
| Price: | USD1-10000/Set |
| Packaging Details: | Plywood case |
| Payment Terms: | L/C, T/T, Western Union |
Bosch Handheld Screwdriver Bit Screw Feeder Machine / Screw Fastening
Features:
1. Small size, low noise, light weight, can be stored on the working platform, saving space.
2. The screws are automatically arranged, feeding, automatic replenishment of empty materials, and has alarm function when there is no screws.
3. Feeding adopts sensor control, torque feedback, automatic feeding, no repeated feeding phenomenon.
4. Sliding tooth feeding material: During the locking process, if the torque is not enough, the screw is replenished to prevent the jamming phenomenon.
5. Counting function: It can selectively start the counting function, set the number of discharging according to the product requirements, and will not discharge for the last screw.
6. High efficiency, one screw per second.
7. Achieve semi-automatic production, reduce work labor intensity, and provide production efficiency
Specification:
| dimension | 350x230x280mm |
| Weight | 15kgs |
| Air supply | 0.6MPa |
| Power | 110/220V, 30W |
| Screw size | M2-M4 |
| Locking speed | 1-2 second/pc |
| Working distance | 2M |
Application:
Toy, LCD/LED modules, communication equipment, electrical appliances, auto parts and so on.
|
|
| Brand Name: | Winsmart |
| Model Number: | SMTSD8101 |
| MOQ: | 1 set |
| Price: | USD1-10000/Set |
| Packaging Details: | Plywood case |
| Payment Terms: | L/C, T/T, Western Union |
Bosch Handheld Screwdriver Bit Screw Feeder Machine / Screw Fastening
Features:
1. Small size, low noise, light weight, can be stored on the working platform, saving space.
2. The screws are automatically arranged, feeding, automatic replenishment of empty materials, and has alarm function when there is no screws.
3. Feeding adopts sensor control, torque feedback, automatic feeding, no repeated feeding phenomenon.
4. Sliding tooth feeding material: During the locking process, if the torque is not enough, the screw is replenished to prevent the jamming phenomenon.
5. Counting function: It can selectively start the counting function, set the number of discharging according to the product requirements, and will not discharge for the last screw.
6. High efficiency, one screw per second.
7. Achieve semi-automatic production, reduce work labor intensity, and provide production efficiency
Specification:
| dimension | 350x230x280mm |
| Weight | 15kgs |
| Air supply | 0.6MPa |
| Power | 110/220V, 30W |
| Screw size | M2-M4 |
| Locking speed | 1-2 second/pc |
| Working distance | 2M |
Application:
Toy, LCD/LED modules, communication equipment, electrical appliances, auto parts and so on.
