| Brand Name: | Winsmart |
| Model Number: | SMTAD5 |
| MOQ: | 1 set |
| Price: | USD1-10000/set |
| Packaging Details: | Plywood case |
| Payment Terms: | L/C, T/T, Western Union |
Unlimited Motorized LED PCB Separator Machine Available For 1200mm Boards
Features:
1. Adjustable separating speed: 500mm/s or 300mm/s.
2. Upper circular blade can be adjustable 0-2mm.
3. Operation platform is adjustable 0-50mm.
4. Cutting thickness: 0.2-3.2mm, V-cut thickness: 0.2-2.0mm
5. The machine cut PCB boards without damaging electronic components. And it can improve efficiency
6. With blade moving, it can reduce pressure on board to avoid solder joint crack and parts fracture.
7. Upper circular blade cuts against lower linear blade to separate PCB board, smooth and clear cuts.
8. According to the width of PCB, the back baffle can be adjustable from 0 to 150mm.
9. The blades are sharp and indurable. And they can be sharpened between 3 and 5 times.
10. Assemble light curtain system on the end of the lower blade for your option. If there is anything beyond the safe line, PCB separator will stop working to ensure safety operation.
Specification:
| Model | SMTAD5 |
| Machine Dimension | L1540*W600*H460 mm |
| Max Cutting Length | 1200mm |
| PCB Material | FR4, MCPCB |
| Cutting Speed | 300mm/s or 500mm/s |
| PCB Thickness | 0.6-2.0mm |
| Power | 220/110V |
| Machine Weight | 135kgs |
| Wooden Case Dimension | 116x67x62cm |
| Gross Weight | 180kgs |
Spare Parts Available:
Circular blade replacement
Linear blade replacement
Blade resharpening service
|
|
| Brand Name: | Winsmart |
| Model Number: | SMTAD5 |
| MOQ: | 1 set |
| Price: | USD1-10000/set |
| Packaging Details: | Plywood case |
| Payment Terms: | L/C, T/T, Western Union |
Unlimited Motorized LED PCB Separator Machine Available For 1200mm Boards
Features:
1. Adjustable separating speed: 500mm/s or 300mm/s.
2. Upper circular blade can be adjustable 0-2mm.
3. Operation platform is adjustable 0-50mm.
4. Cutting thickness: 0.2-3.2mm, V-cut thickness: 0.2-2.0mm
5. The machine cut PCB boards without damaging electronic components. And it can improve efficiency
6. With blade moving, it can reduce pressure on board to avoid solder joint crack and parts fracture.
7. Upper circular blade cuts against lower linear blade to separate PCB board, smooth and clear cuts.
8. According to the width of PCB, the back baffle can be adjustable from 0 to 150mm.
9. The blades are sharp and indurable. And they can be sharpened between 3 and 5 times.
10. Assemble light curtain system on the end of the lower blade for your option. If there is anything beyond the safe line, PCB separator will stop working to ensure safety operation.
Specification:
| Model | SMTAD5 |
| Machine Dimension | L1540*W600*H460 mm |
| Max Cutting Length | 1200mm |
| PCB Material | FR4, MCPCB |
| Cutting Speed | 300mm/s or 500mm/s |
| PCB Thickness | 0.6-2.0mm |
| Power | 220/110V |
| Machine Weight | 135kgs |
| Wooden Case Dimension | 116x67x62cm |
| Gross Weight | 180kgs |
Spare Parts Available:
Circular blade replacement
Linear blade replacement
Blade resharpening service
