| Brand Name: | Winsmart |
| Model Number: | SMTSR123 |
| MOQ: | 1 set |
| Price: | USD1-10000/Set |
| Packaging Details: | Plywood case |
| Payment Terms: | L/C, T/T, Western Union |
Industrial Soldering Equipment Double Head Soldering Machine
Soldering Robot Main Features:
1. Contains BASIC interpreter, simple programming, direct handle teaching, you can directly enter the welding point coordinates, but also teach welding position, can reproduce the welding position coordinates.
2. Using multi-axis robots and advanced motion control algorithms for linkage to simulate the action of human hand plus tin, effectively improving the positioning accuracy of the iron head.
3. The program has built-in multi-dimension soldering method, spot welding and drag welding. All process parameters can be set by the user. It can simulate various difficult and micro soldering processes of human hands.
Soldering Robot Specifications:
1. Drive mode: X/Y/Z/R four-axis microstepping motor
2. Resolution: X/Y/Z triaxial 0.02mm
3. Control mode: PTP point-to-point, CP continuous path teaching control, can teach repeatedly.
4. Enter air pressure: 4-6kgf/cm2
5. Output/input: 4 inputs, 4 outputs.
6. Dimension:L680*W500*H720mm
7. Weight: 80kg
Soldering Robot Parameters:
| Model | SMTSR123 |
| Dimension | 680*500*720mm |
| Weight | 80Kg |
| Control | PLC |
| Programming | Teaching box |
| Driving mode | Stepper motor |
| Stroke | 400(X)x300(Y1)x300(Y2)x80(Z) |
| Soldering head | 2 |
| Repeatability | ±0.02mm(X/Y/Z) |
| Temp. Range | 0-550℃ |
| Solder Wire Spec | ￠0.3-1.6mm |
| Number of axes | 4 |
| Working pressure | 0.4~0.6Mpa(No water mist) |
| Power | AC110V/220V 300W |
| Display | LCD |
Robotic Soldering Machine Application:
Robotic Soldering Machine FAQ:
Q: What is soldering time?
A: About 2 seconds per point.
Q: What kind of soldering tips can you offer?
A: We could customize make suitable shape of soldering tip according to your application.
Q: What kind of heater?
A: Weller brand.
Q: Is it possible to change parameters for only one soldering point?
A: Yes, it is ok.
Q: How to improve soldering effect when trial soldering is not good?
A: It can be improved by solder wire feeding and soldering time adjustment.
|
