| Brand Name: | Winsmart |
| Model Number: | SMTAD1 |
| MOQ: | 1 set |
| Price: | USD1-10000/set |
| Packaging Details: | Plywood case |
| Payment Terms: | L/C, T/T, Western Union |
110/220V Power Supply Circular Blade And Linear Blade Automatic PCB Depanelizer
PCB Depanelizer Description:
A PCB depanelizer is a specialized machine used in electronics manufacturing to separate individual printed circuit boards (PCBs) from a larger panel or array. These machines are designed to cut, score, or route along predefined lines on the panel to separate the individual PCBs cleanly and accurately.
PCB Depanelizer Specifications:
| Model | SMTAD1 |
| Max Cutting Length | 460mm |
| Dimension | 740*550*460mm |
| Cutting point | 0-100-200-300-400mm |
| Cutting Speed | 300mm/s ,500mm/s |
| Cutter point angle | 26~28° |
| Conveyor Belt (Options) | 1.5m |
| Cutting thickness | 0.6-5.0mm |
| Minimum component distance from v-groove | 1mm |
| Voltage | 220 V or 110V, 50/60HZ, 250W |
| Max component height | 30 mm |
| Origin of country | China |
| Condition | New |
| Warranty | 1 year |
| Automatic | Yes |
| Package | Wooden case |
| Certification | CE approval |
| Machine weight | 65kg / 85kg |
| Machine Warranty period |
1 year |
PCB Depanelizer Installation:
1. Environment setting
1.1 The equipment should be installed in a ventilated and dry place. Do not install it in a place that is easy to corrode or flammable.
1.2 Do not place the equipment in the place with strong vibration and easy collision.
2. Mechanical installation
Place the equipment in the working table.
PCB Depanelizer Features:
1. Microcomputer program control, precise positioning and good stability.
2. Separate pre-scored PCB assembly without stress on either PCB or component;
3. One touch programming of cut length with digital display;
4. Separating speed is adjusted by a rotary knob;
5. Handle Intermittent scoring or cut-outs;
6. Board with projected component can be cut precisely;
7. Large stainless steel platform on both side of cutting lade prevents board wobble and table height and angle are adjustable;
8. Clearance between circular and linear blades are adjustable to fit different groove depth and compensates for blade wear out.
PCB Depanelizer Applications:
The machines can be manual, semi-automatic, or fully automatic, with varying levels of precision, throughput, and complexity depending on the specific requirements of the manufacturing process.
It is widely used in industries of electronics manufacturing, automotive electronics, telecommunications, medical electronics, aerospace and defense, consumer electronics, LED lighting & renewable energy.
PCB Depanelizer Packaging:
|
|
| Brand Name: | Winsmart |
| Model Number: | SMTAD1 |
| MOQ: | 1 set |
| Price: | USD1-10000/set |
| Packaging Details: | Plywood case |
| Payment Terms: | L/C, T/T, Western Union |
110/220V Power Supply Circular Blade And Linear Blade Automatic PCB Depanelizer
PCB Depanelizer Description:
A PCB depanelizer is a specialized machine used in electronics manufacturing to separate individual printed circuit boards (PCBs) from a larger panel or array. These machines are designed to cut, score, or route along predefined lines on the panel to separate the individual PCBs cleanly and accurately.
PCB Depanelizer Specifications:
| Model | SMTAD1 |
| Max Cutting Length | 460mm |
| Dimension | 740*550*460mm |
| Cutting point | 0-100-200-300-400mm |
| Cutting Speed | 300mm/s ,500mm/s |
| Cutter point angle | 26~28° |
| Conveyor Belt (Options) | 1.5m |
| Cutting thickness | 0.6-5.0mm |
| Minimum component distance from v-groove | 1mm |
| Voltage | 220 V or 110V, 50/60HZ, 250W |
| Max component height | 30 mm |
| Origin of country | China |
| Condition | New |
| Warranty | 1 year |
| Automatic | Yes |
| Package | Wooden case |
| Certification | CE approval |
| Machine weight | 65kg / 85kg |
| Machine Warranty period |
1 year |
PCB Depanelizer Installation:
1. Environment setting
1.1 The equipment should be installed in a ventilated and dry place. Do not install it in a place that is easy to corrode or flammable.
1.2 Do not place the equipment in the place with strong vibration and easy collision.
2. Mechanical installation
Place the equipment in the working table.
PCB Depanelizer Features:
1. Microcomputer program control, precise positioning and good stability.
2. Separate pre-scored PCB assembly without stress on either PCB or component;
3. One touch programming of cut length with digital display;
4. Separating speed is adjusted by a rotary knob;
5. Handle Intermittent scoring or cut-outs;
6. Board with projected component can be cut precisely;
7. Large stainless steel platform on both side of cutting lade prevents board wobble and table height and angle are adjustable;
8. Clearance between circular and linear blades are adjustable to fit different groove depth and compensates for blade wear out.
PCB Depanelizer Applications:
The machines can be manual, semi-automatic, or fully automatic, with varying levels of precision, throughput, and complexity depending on the specific requirements of the manufacturing process.
It is widely used in industries of electronics manufacturing, automotive electronics, telecommunications, medical electronics, aerospace and defense, consumer electronics, LED lighting & renewable energy.
PCB Depanelizer Packaging:
