| Brand Name: | Winsmart |
| Model Number: | SMTL350 |
| MOQ: | 1 set |
| Price: | USD1-150K/set |
| Packaging Details: | Plywood case |
| Payment Terms: | L/C, T/T, Western Union |
Laser PCB Cutting Machine Scanning Speed 2500mm/s and 40x40mm Field
Laser PCB Cutting Machine Function:
The equipment is mainly used in the cutting 5G materials such as CCM / COB / LCP / MPI / COF / cop / pi / CPI in consumer electronics. The equipment integrates high-speed and high-precision optical processing system, independent process and processing path optimization system, which can accurately cut the shape and control the half cutting depth. The application of ultra short pulse ultraviolet laser has greatly improved the processing quality of products.
Laser PCB Cutting Machine Introduction:
The gantry structure and flying light path design make it easy to connect to the production line. It can be equipped with a special
loading and unloading IN-LINE system according to production needs to realize automatic production and greatly improve production efficiency.It is a device tailored for FPC and PCB processing. The working mode of the ordinary cutting machine can realize assembly line operation and double-station production,the smart model design,the closed optical path system can process products within450,which can be separated into a double platform 200 range,it is tailor-made for FPC and PCB processing.
Laser PCB Cutting Machine Features:
1. Effectively control the processing heat effect, and improve the edge collapse and thermal effect of the product
2. High quality laser, no contact processing, no burr and burr after cutting
3. Mature process system can accurately calculate and segment the graphics, and realize the process of processing parameters and processing graphics
4. Application fields: pcb/fpc/pi/cpi/mpi/pcba/cof/cop/cob/fr4/lcp, etc
Laser PCB Cutting Machine Specification:
| Laser | UV, picosecond |
| Laser Wavelength | 355nm |
| Laser Source | Optional |
| Positioning Precision of Worktable of Linear Motor | ±3μm |
| Repetition Precision of Worktable of Linear Motor | ±2μm |
| Effective Working Field | 350mmx400mm(twin tables) |
| Scanning Speed | 2500mm/s (max) |
| Working field | 50mmх50mm |
Laser PCB Cutting Machine Advantages:
Lasers make clean, burr-free and precise cuts against the edge of circuits and other important components—improving overall design flexibility without damaging the substrate. Because you don’t have to reorder parts or sharpen bits and blade, laser systems are also more cost effective.
|
