| Brand Name: | Winsmart |
| Model Number: | SMTD3 |
| MOQ: | 1 set |
| Packaging Details: | Plywood case |
| Payment Terms: | L/C, T/T, Western Union |
Mulit Blade Aluminum LED PCB Separator LED PCB Cutting Machine
LED PCB Separator Introduction:
1. Equipment designed to minimize board stress and avoid component damage.
2. Five pairs of precision beveled cutting blades ensure the board does not bend or deform.
3. The guide can be adjusted vertically to suit different LED boards.
4. Depth between upper circular blades can be precisely adjusted to reduce stress on score line edge and blade wear.
LED PCB Separator Features:
1. Separates panels up to 0.1"
2. The longest panel: No limit
3. Minimum board thickness of 0.024"
4. Shears boards safely with parts as close as 0.02" to score line.
5. Only allow correct boards placement to avoid mistakes.
LED PCB Separator Specification:
| Model | SMTD3L |
| Machine Dimension | 400x400x330mm |
| Platform Dimension | 2400x300x200mm |
| Max Cutting Length | No limit |
| PCB Material | FR4, MCPCB, Copper Boards |
| Cutting Speed | 0-500mm/s |
| PCB Thickness | 0.6-3mm |
| Power | 220/110V |
| Machine Weight | 50kgs |
| Wooden Case Dimension | 116x67x58cm |
| Gross Weight | 85kgs |
LED PCB Separator Blades:
|
|
