| Brand Name: | Winsmart |
| Model Number: | SMTR05 |
| MOQ: | 1 Set |
| Price: | USD1-100000 |
| Packaging Details: | Plywood case |
| Payment Terms: | T/T, L/C, Western Union |
Semi Auto 60000rpm Spindle PCB Router Machine with 3HP Vacuum Cleaner
Semi-auto Spindle PCB Router Introduction:
When considering the numerous methods available for PCB singulation, it is difficult to decide which might be the best. In China we propose that our PCB routers are the most efficient, and quickest way to singulate PCB's. For stress free depanelization we utilize a router bit which minimizes the stress on components, therefore keeping them intact and working proficiently. The router bit adjustment system will automatically shift up to 4 different depth levels, which will cut down on bit replacement. Our PCB routers also contain a high speed spindle which will sustain precision while speeding up the process.
Semi-auto Spindle PCB Router Features:
1. Two-slide PCB Separator
2. Low stress
3. Sharp cutting edge
4. Manul loading /unloading
5. High speed cutting by 4 axes control(XY moving at the same time)
6. Easy teaching with image processing
Semi-auto Spindle PCB Router Specifications:
| Router Machine | SMTR05 |
| X/Y Cutting Speed | 0 ~100mm/s |
| Repeatability precision | ± 0.01mm |
| X/Y1/Y2/Z control mode | Industrial IPC and PC |
| X/Y1/Y2/Z driven mode | AC Servo Motor |
| Operation and data storage | PC |
| Cutting Precision | ± 0.05mm |
| Spindle Speed | 60000rpm(Germany KKAVO) |
| Power Supply | 220V/110V |
| Air Pressure | 4.5kg/cm 2 |
| Power Rate | 1.8KW |
| Vacuum Cleaner | |
| Mode | Up or Bottom |
| Power Supply | 380V |
| Up Cleaner Dimension | L650*W400*H1350mm |
| Bottom Cleaner Dimension | L665*W635*H1650mm |
Semi-auto Spindle PCB Router Advantages:
Firsly, it has the advantage of long tool life. After cutting a certain distance, the milling cutter will automatically rise / fall to another uncut blade position according to the setting. The up-down distance and times can be set freely according to the blade length to prolong the service life of the milling cutter. In addition, there is a power-off memory function. In normal use, in case of sudden power failure, the automatic PCB depaneling router machine system will notify the processing steps in case of power failure. Also, it can replace manual crushing, V-cut cutting, push cutting and other cutting defects, improve product quality and reduce scrap rate. Finally, the program can be set and entered manually. It has the functions of import and export, board connection copy, path copy, editing and modification, etc. It can simplify program making and save time.
Our Service:
1. Lifetime technical support and 2 years warranty.
2. Free replacement or refund would be done in case of any quality problem.
3. Fast response/feedback within 12 hours
4. Engineers are available to be sent to do oversea installation and training.
5. Solid packaging to prevent damage from transportation.
|
|
