| Brand Name: | Winsmart |
| Model Number: | SMTL300 |
| MOQ: | 1 set |
| Price: | USD1-150K/set |
| Packaging Details: | Plywood case |
| Payment Terms: | L/C, T/T, Western Union |
Non-contact ±2μm Cutting Precision Laser PCB Machine Depaneling PCB
Laser PCB Machine Advantages:
No dust, good to PCB conductivity.
No stress, ±5μm cutting precision
Could import gerber file for easy operation
Alien/line cutting is available
Non-contact, smooth cutting edge
Laser PCB Machine Working Principle:
Manual/auto feed PCB/FPC on the platform -> Vacuum adsorption FPC/Customized fixture fix PCB -> Camera CCD system scan mark points -> Auto positioning -> Program running -> Laser cutting -> Separated single PCB/FPC collection.
Laser PCB Machine Features:
Effectively control the processing heat effect, and improve the edge collapse and thermal effect of the product.
High quality laser, no contact processing, no burr and burr after cutting.
Mature process system can accurately calculate and segment the graphics, and realize the process of processing parameters and processing graphics
Application fields: pcb/fpc/pi/cpi/mpi/pcba/cof/cop/cob/fr4/lcp, etc
Laser PCB Machine Specifications:
| Laser | solid-state UV laser |
| Laser Wavelength | 355nm |
| Laser Source | UV 15W@30KHz |
| Positioning Precision | ±2μm |
| Repetition Precision | ±1μm |
| Working Area | 300mmx350mm(Customizable) |
| Scanning Speed | 2500mm/S |
| Cutting Speed | Less 2500mm/S |
| Cutting Path | Line, Curve, Circle, Alien |
| Air Pressure | 0.6-0.8MPa |
| Dimension | 1250x1250x1740mm |
| Weight | 1500kgs |
|
| Brand Name: | Winsmart |
| Model Number: | SMTL300 |
| MOQ: | 1 set |
| Price: | USD1-150K/set |
| Packaging Details: | Plywood case |
| Payment Terms: | L/C, T/T, Western Union |
Non-contact ±2μm Cutting Precision Laser PCB Machine Depaneling PCB
Laser PCB Machine Advantages:
No dust, good to PCB conductivity.
No stress, ±5μm cutting precision
Could import gerber file for easy operation
Alien/line cutting is available
Non-contact, smooth cutting edge
Laser PCB Machine Working Principle:
Manual/auto feed PCB/FPC on the platform -> Vacuum adsorption FPC/Customized fixture fix PCB -> Camera CCD system scan mark points -> Auto positioning -> Program running -> Laser cutting -> Separated single PCB/FPC collection.
Laser PCB Machine Features:
Effectively control the processing heat effect, and improve the edge collapse and thermal effect of the product.
High quality laser, no contact processing, no burr and burr after cutting.
Mature process system can accurately calculate and segment the graphics, and realize the process of processing parameters and processing graphics
Application fields: pcb/fpc/pi/cpi/mpi/pcba/cof/cop/cob/fr4/lcp, etc
Laser PCB Machine Specifications:
| Laser | solid-state UV laser |
| Laser Wavelength | 355nm |
| Laser Source | UV 15W@30KHz |
| Positioning Precision | ±2μm |
| Repetition Precision | ±1μm |
| Working Area | 300mmx350mm(Customizable) |
| Scanning Speed | 2500mm/S |
| Cutting Speed | Less 2500mm/S |
| Cutting Path | Line, Curve, Circle, Alien |
| Air Pressure | 0.6-0.8MPa |
| Dimension | 1250x1250x1740mm |
| Weight | 1500kgs |
