| Brand Name: | Winsmart |
| Model Number: | SMTR05 |
| MOQ: | 1 Set |
| Price: | USD1-100000 |
| Packaging Details: | Plywood case |
| Payment Terms: | T/T, L/C, Western Union |
17 Inch LCD Programming CCD System PCBA Cutting Machine PCB Depaneling Router
PCBA Cutting Machine Overview:
PCB router machine is a machine for depaneling irregular PCB boards connected by stamp holes. Also known as PCB router machine, desktop PCB router machine, stamp hole PCB depaneling router. PCB router machine is an important process in the PCB manufacturing process. PCB router refers to cutting the graphics required by the customer through the routing bits according to the processing program designed by the project.
PCBA Cutting Machine Features:
1. Floor type, dual tables, suitable for high volume production.
2. Continuous cutting without interruption during loading and unloading.
3. The high-quality rotating shaft system enables the system to accelerate and decelerate quickly, reduce the synchronization time, improve productivity and maintain high precision.
4. High quality hardware is used to ensure high rigidity and high performance.
5. Dust free and noise free.
6. Low stress to ensure smooth cutting edge.
PCBA Cutting Machine Specifications:
| Router Machine | SMTR05 |
| X/Y Cutting Speed | 0 ~100mm/s |
| Repeatability precision | ± 0.01mm |
| X/Y1/Y2/Z control mode | Industrial IPC and PC |
| X/Y1/Y2/Z driven mode | AC Servo Motor |
| Operation and data storage | PC |
| Cutting Precision | ± 0.05mm |
| Spindle Speed | 60000rpm(Germany KKAVO) |
| Power Supply | 220V/110V |
| Air Pressure | 4.5kg/cm 2 |
| Power Rate | 1.8KW |
| Vacuum Cleaner | |
| Mode | Up or Bottom |
| Power Supply | 380V |
| Up Cleaner Dimension | L650*W400*H1350mm |
| Bottom Cleaner Dimension | L665*W635*H1650mm |
PCBA Cutting Machine Application:
|
