| Brand Name: | Winsmart |
| Model Number: | SMTD1 |
| MOQ: | 1 set |
| Price: | USD1-10000/set |
| Packaging Details: | Plywood case |
| Payment Terms: | L/C, T/T, Western Union |
Automatic 1200mm LED PCB Separator Machine LED PCB Cutting Machine
Specification:
| Model | SMTD1 |
| Machine Dimension | 280x420x400mm |
| Platform Dimension | 2400x500x400mm |
| Max Cutting Length | No limit |
| PCB Material | FR4, MCPCB, Copper Boards |
| Cutting Speed | 0-400mm/s |
| PCB Thickness | 0.8-3mm |
| Power | 220/110V |
| Machine Weight | 43kgs |
| Wooden Case Dimension | 116x67x58cm |
| Gross Weight | 76kgs |
Features:
1. Easy operation, high cutting speed.
2. The upper knife distance can be precisely adjusted to solve the V-cut problem, and the stress generated by the cutting plate is reduced to avoid tin cracking.
3. Upper and lower round knives can be adjusted precisely, suitable for led strip panels.
4. Blade is made of imported high speed steel which is durable.
5. Cutting speed is adjustable according to different application.
6. Blades are re-sharpened
Technical Parameter:
|
A : > 0.25mm B: 1.0mm(Max)
Standard cutter : C2: ≧2mm C1: ≧0.3mm Θ: ≧200
|
| Max.Cutting length (mm) | Unlimited |
| Cutting thickness (mm) | 0.8~2.0 |
| Cutting Speed (mm/s) | 0~400 |
| Voltage (VAC) | 230 |
| Machine Weight (KG) | 65 |
|
|
