| Brand Name: | Winsmart |
| Model Number: | SMTL600 |
| MOQ: | 1 set |
| Price: | USD1-150K/set |
| Packaging Details: | Plywood case |
| Payment Terms: | L/C, T/T, Western Union |
CNC FPC UV Laser Cutting Machine PCB Depaneling for Precise Cutting
CNC Laser Cutting Machine Overview:
The equipment is mainly used in the cutting 5G materials such as CCM / COB / LCP / MPI / COF / cop / pi / CPI in consumer electronics. The equipment integrates high-speed and high-precision optical processing system, independent process and processing path optimization system, which can accurately cut the shape and control the half cutting depth. The application of ultra short pulse ultraviolet laser has greatly improved the processing quality of products.
CNC Laser Cutting Machine Specification:
| Laser | Q-Switched diode-pumped all solid-state UV laser |
| Laser Wavelength | 355nm |
| Laser Source | Optowave UV 15W@30KHz |
| Positioning Precision of Worktable of Linear Motor | ±2μm |
| Repetition Precision of Worktable of Linear Motor | ±1μm |
| Effective Working Field | 600mmx600mm(Customizable) |
| Scanning Speed | 2500mm/s (max) |
| Working field | 40mmх40mm |
CNC Laser Cutting Machine Features:
1. No mechanical stress.
2. Lower tooling costs.
3. Higher quality of cuts.
4. No consumables.
5. Design versatility-simple software changes enable application changes.
6. Works with any surface-Teflon, ceramic, aluminum, brass and copper.
7. Fiducial recognition achieves precise.
8. Lasers make clean, burr-free and precise cuts against the edge of circuits and other important components - improving overall design flexibility without damaging the board.
CNC Laser Cutting Machine Function:
The processing and application objects are PCB, FPC soft and hard plate and related material cutting, cover opening and other operations.
Efficient integration of all components of the equipment, including laser, optical path, galvanometer system, 4-axis motion platform and image
System to achieve efficient and accurate operation.
|
