| Brand Name: | Winsmart |
| Model Number: | PM0409 |
| MOQ: | 1 PC |
| Price: | USD1-100/Set |
| Packaging Details: | Plywood case |
| Payment Terms: | L/C, T/T, Western Union |
Gear Adjustable Magazine Rack, Plastic, 355x320x563mm, 80-120°C
Gear Adjustable Magazine Rack Function:
It is for use with in-line automation.
Gear Adjustable Magazine Rack Features:
1. Fast and simple gear adjusting card guide to maintain parallelism and ensure accurate setup
2. Plastic top and bottom
3. Zero flexing of card guides with steel reinforcing supports and molded ribs
4. Standard ABS model (N) tolerates 60°C, plus optional models to 120°C (M) and 200°C (H)
5. Surface resistivity of 10-4 to 10-6 ohm/cm
6. Removable end stop
7. Carrying handles on top and bottom
Gear Adjustable Magazine Specification:
Surface resistance: 10e 5 ~10e 9 Ω
Heat-resistance:80 °C/120°C/200°C
Overall Size:different size availabe, please refer below
Max. qty to store PCB:50pcs
Suitable PCB Size:different size availabe, please refer below
Side guid slot:depth 3.0mm, width 5.0mm, pitch 10mm
Adjustable method:Gear Tracker / Screws
Gear Adjustable Magazine Rack Dimensions:
1. Dimension: 355x320x563mm, storing 50pcs of 350x(50-250)MM PBC Boards
Depth 3.5mm, width 5mm, pitch 10mm
2. Dimension: 355x315x580mm, storing 50pcs of 350x(80-250)MM PBC Boards
Depth 3.5mm, width 5mm, pitch 10mm
3. Dimension: 460x400x563mm, storing 50pcs of 460x(100-330)MM PBC Boards
Depth 3.5mm, width 5mm, pitch 10mm
4. Dimension: 535x460x570mm, storing 50pcs of 535x(50-390)MM PBC Boards
Depth 3.5mm, width 5mm, pitch 10mm
5. Dimension: 535x530x570mm, storing 50pcs of 535x(50-460)MM PBC Boards
Depth 3.5mm, width 5mm, pitch 10mm
Gear Adjustable Magazine Rack Parameters:
| Name | ESD PCB Magazine Rack |
| Surface resistance | 104~106 Ω |
| Overall size | 355x320x563mm |
| Storage capacity | 50pcs |
| PCB Spec | L355xW(50-250)mm |
| Side guide slot | depth 3.5mm, width 5mm, pitch 10mm |
| Heat resistant | 80°C/120°C/200 °C |
| Ref. Position | A=34mm, B=34mm |
| Materials | Aluminum + steel |
Gear Adjustable Magazine Rack
A PCB magazine or PCB rack is made of volume conductive polypropylene and metal, which is used to turansport the PCB boards for automated assembly lines. The PCB magazine racks are an ideal aid in the production, storage and transportation of PCBs. The strong and robust sidewall and metal frame guarantee that these PCB magazine racks are durable.
|
|
