| Brand Name: | Winsmart |
| Model Number: | SMTR05 |
| MOQ: | 1 Set |
| Price: | USD1-100000 |
| Packaging Details: | Plywood case |
| Payment Terms: | T/T, L/C, Western Union |
Tab Board PCB Cutting Machine Milling Cutter PCB Depaneling Router 400x400mm
Milling Cutter PCB Depaneling Router Features:
1. Dual working table for high volume product, with speed up to 100mm / s and positioning speed of 500mm/s.
2. Continuous cutting without interruption during loading and unloading.
3. The high-quality rotating shaft system enables the system to accelerate and decelerate quickly, reduce the synchronization time, improve productivity and maintain high precision.
4. High quality hardware is used to ensure high rigidity and high performance.
5. Imported spingle ensures perfect cutting effect.
6. Optional top and bottom cleaning systems to meet different application requirements.
Milling Cutter PCB Depaneling Router Specifications:
| Router Machine | SMTR05 |
| X/Y Cutting Speed | 0 ~100mm/s |
| Repeatability precision | ± 0.01mm |
| X/Y1/Y2/Z control mode | Industrial IPC and PC |
| X/Y1/Y2/Z driven mode | AC Servo Motor |
| Operation and data storage | PC |
| Cutting Precision | ± 0.05mm |
| Spindle Speed | 60000rpm(Germany KKAVO) |
| Power Supply | 220V/110V |
| Air Pressure | 4.5kg/cm 2 |
| Power Rate | 1.8KW |
| Vacuum Cleaner | |
| Mode | Up or Bottom |
| Power Supply | 380V |
| Up Cleaner Dimension | L650*W400*H1350mm |
| Bottom Cleaner Dimension | L665*W635*H1650mm |
Milling Cutter PCB Depaneling Router Maintenance:
1. It is necessary to check whether there are materials falling from the electric cabinet. If so, it needs to be cleaned in time and maintained daily. About the maintenance method of the front and rear panels of the host: the front and rear panels of the host need to be wiped every day.
2. XYZ motor wiring and maintenance method of origin limit sensor: generally, the sensor shall be wiped with external dust and oil stain once a day.
3. About the maintenance method of the iron plate at the bottom of the main engine: if the parts fall, they need to be removed and replaced in time.
4. About the maintenance method of the three-point combination: check whether there is water in the water filter cup every day. If there is water, press the Yellow drain to remove it.
5. Maintenance method of spindle: wipe and clean the spindle when the machine stops working every day.
6. Maintenance method of vacuum cleaner: wipe and clean the vacuum cleaner after the machine stops working every day.
|
|
