6-Blade LED Bench Top PCB Separator Machine For Aluminum PCB Boards
LED PCB Separator Machine Features:
1. Separation length: no limit
2. Platform length: 2400mm
3. Minimum board thickness of 2.5mm
4. 6-blades sharing cutting stress for smooth cutting
5. Adjustable cutting speed, suitable for high volume production, 2000pcs/hour
LED PCB Separator Machine PCB Parameter:
A : > 0.25mm
B: 1.0mm(Max)
Standard cutter :
C2: ≧1mm C1: ≧1mm
Θ: ≧280
LED PCB Separator Machine Specification:
| Model | SMTD3 |
| Machine Dimension | 400x400x330mm |
| Platform Dimension | 2400x300x200mm |
| Max Cutting Length | No limit |
| PCB Material | FR4, MCPCB, Copper Boards |
| Cutting Speed | 0-500mm/s |
| PCB Thickness | 0.6-3mm |
| Power | 220/110V |
| Machine Weight | 50kgs |
| Wooden Case Dimension | 116x67x58cm |
| Gross Weight | 76kgs |
LED PCB Separator Machine Application:
It is widely used in LED lighting industry, suitable for both FR4 and Aluminum PCB boards, and it has no limit on cutting length.
LED PCB Separator Machine Blade Adjustment:
1. If the separated board is twisted, means that the three groups of knives are overcut, then we need to adjust the third upper knife, and raise the knife a little bit, so that the board can be cut without deformation.
2. If the separated board is bent, we need to adjust the two blocks on the right. If the board is concave bent, it means that the force of the block to the board edge is small. In this way, the block is closer to the board edge. If the convex bending occurs, it means that the force of the block to the board edge is large, then move the block out a little.
3. If the board is not cut off at one time, then we need to adjust the third upper knife down a little to make smaller blade clearance.
|
