| Brand Name: | Winsamrt |
| Model Number: | SMTP330 |
| MOQ: | 1 set |
| Price: | USD1-10000/set |
| Packaging Details: | Plywood case |
| Payment Terms: | L/C, T/T, Western Union |
LED PCB Punch Depaneling Machine With Customized Die Tooling
PCB Punch Depaneling Machine Features:
1. FPC, FR4 and Aluminum PCB boards are available.
2. Optional output 3T, 8T, 10T, 15T and 30T is available.
3. It is easy to replace punching mold for new PCB boards.
4. Loading and unloading PCBs is convenient.
PCB Punch Depaneling Machine Advantages:
1. Cylinder air driven, environmental protection.
2. High efficiency, suitable for high volume PCBs.
3. Security door protection and sensor safe system, ensure safe production without accident.
PCB Punch Depaneling Machine Specification:
| Working area | 460*320mm |
| Working pressure | 0.45-0.7Mpa |
| Cutting precision | ±0.05mm |
| Cycle time | 7-15 seconds |
| Output | 8T |
| PCB/FPC thickness | 0.08-3.5MM |
| PCB/FPC material | FPC, FR1, FR4, CEM-1, CEM-3, MCPCB |
| Cutting mode | Punching |
| Punch fixture | Die tooling(mold) |
| Working Property |
LCD display, Automatically records the number of processed products, automatic punching |
| Transmission port | International standard |
| Operation Language | English |
| Stroke | 50MM |
| Mold height | 170MM |
| Power | 380/220V |
| Fuse | 3A |
| Machine dimension | 820x740x1750mm |
| Machine weight | 680kgs |
PCB Punch Depaneling Machine Application:
It is widely used in mobile phone, LED industry, toys manufacturing.
PCB Punch Depaneling Machine Die Tooling:
|
| Brand Name: | Winsamrt |
| Model Number: | SMTP330 |
| MOQ: | 1 set |
| Price: | USD1-10000/set |
| Packaging Details: | Plywood case |
| Payment Terms: | L/C, T/T, Western Union |
LED PCB Punch Depaneling Machine With Customized Die Tooling
PCB Punch Depaneling Machine Features:
1. FPC, FR4 and Aluminum PCB boards are available.
2. Optional output 3T, 8T, 10T, 15T and 30T is available.
3. It is easy to replace punching mold for new PCB boards.
4. Loading and unloading PCBs is convenient.
PCB Punch Depaneling Machine Advantages:
1. Cylinder air driven, environmental protection.
2. High efficiency, suitable for high volume PCBs.
3. Security door protection and sensor safe system, ensure safe production without accident.
PCB Punch Depaneling Machine Specification:
| Working area | 460*320mm |
| Working pressure | 0.45-0.7Mpa |
| Cutting precision | ±0.05mm |
| Cycle time | 7-15 seconds |
| Output | 8T |
| PCB/FPC thickness | 0.08-3.5MM |
| PCB/FPC material | FPC, FR1, FR4, CEM-1, CEM-3, MCPCB |
| Cutting mode | Punching |
| Punch fixture | Die tooling(mold) |
| Working Property |
LCD display, Automatically records the number of processed products, automatic punching |
| Transmission port | International standard |
| Operation Language | English |
| Stroke | 50MM |
| Mold height | 170MM |
| Power | 380/220V |
| Fuse | 3A |
| Machine dimension | 820x740x1750mm |
| Machine weight | 680kgs |
PCB Punch Depaneling Machine Application:
It is widely used in mobile phone, LED industry, toys manufacturing.
PCB Punch Depaneling Machine Die Tooling:
