| Brand Name: | Winsmart |
| Model Number: | SMTPD2 |
| MOQ: | 1 set |
| Price: | USD1-10000/set |
| Packaging Details: | Plywood case |
| Payment Terms: | L/C, T/T, Western Union |
Metal Core PCB Depanelizer Machine With Customized 600mm Linear Blades
PCB Depanelizer Machine Usages:
It is a necessary electronic equipment for electronic manufacturers. Because PCBA separator machine cuts PCBA board components through the movement of blades, it can more effectively control the stress generated during cutting and prevent the damage and displacement of components. It has greater quality assurance than manual breaking.
PCB Depanelizer Machine Features:
This PCB depanelizer is air driven, and it uses 2 linear blades to separate boards without stress to protect components during cutting. It allows 0.5mm components as close as scoring line, and operator will not misfeed the boards. Max blade clearance is 2 mm to ensure safe operation and avoid accidence. Fpot pedal control, easy to operate, machine is suitable for both FR4 and MCPCB boards depaneling.
PCB Depanelizer Machine Specification:
| Model | SMTPD2 |
| Machine Dimension | 720x300x440mm / 520x300x440mm / 500x300x440mm |
| Max Cutting Length | 330mm / 200mm / 130mm |
| PCB Material | FR4, MCPCB, CEM, Copper Boards |
| Air Pressure | 0.4-0.7MPa |
| PCB Thickness | 0.3-3.5mm |
| Power | 110/220V |
| Machine Weight | 130kgs / 100kgs / 80kgs |
| Cutting Stress | Less than 500u strain |
| Blade Material | High Speed Steel |
| Blade Quantity | 2 |
| Component Height | Max 70mm |
| Blade Lifetime | about 6-12 months |
| Driven Mode | Air |
| Package | Wooden case |
| PCB Collection Fixture | Optional |
| Warranty | 1 Year |
| Machine Condition | New |
PCB Depanelizer Machine Advantanges:
It can separate the board at one time. Not only the installation is convenient, but also the operation setting is simple, which can save many employees, time and labor. It takes up less space and saves operation time. This machine is mainly developed for the intermittent production of products in the LED lighting industry to meet its strict requirements for deformation. This machine is also suitable for copper lamp board, cob board and other board types. It has excellent PCB separator performance and high cost performance.
PCB Depanelizer Machine Photos:
|
