| Brand Name: | Winsmart |
| Model Number: | SMTID5X |
| MOQ: | 1 Unit |
| Price: | USD10000/Unit |
| Packaging Details: | Plywood case |
| Payment Terms: | T/T, Western Union |
Full Automatic Glue Dispensing Machine Offers Different Valve Options
Automatic Glue Dispensing Machine Overview:
The full automatic dispensing system is a flexible machine for dispensing of solder paste, glue, sealant, underfill, conformal coating and more. The range of application are prototyping, serial production, special applications or the extension of production lines.
Automatic Glue Dispensing Machine Features:
1. PC control, Windows 10 operation system.
2. Auto alarm and menu display function.
3. CCD visual position system.
4. Servo motor+ ball screw drive.
5. SMEMA interface communication.
6. Auto feeding and auto unloading.
7. Different types of nozzle are optional according to your glue type.
8. Offers a lot of options for every application.
9. Friendly software for easy programming.
10. Comes with dipping function to prevent glue drying.
Automatic Glue Dispensing Machine Advantages:
1 up to 3 dispensing valves
Time-pressure valves
Pecision dispenser valves
Screw dispeser valves
Jet dispening valves
Spray dispensing system
Dots, lines, circes, free forms
Any dispensing heights
Automatic Glue Dispensing Machine Specification:
| Model | SMTID5X |
| PCB Size | 400x350mm |
| Moving Speed | 500 mm/sec |
| Conveyor Belt Speed | 200 mm/sec |
| Driven Mode | (Stepping + belt) or (servo + screw rod) |
| Program Mode | Visual CCD System |
| Repeatable Precision | ±0.02mm |
| Feeding Mode | Auto |
| Unloading Mode | Auto |
| OS | Windows 10 |
| Communication Port | SMEMA |
| Valve Quantity | 1 |
| Warranty | 1 year |
| Glue Packaging | Up to client's requirement |
| Transport height | 900±20mm |
| Transport direction | L→R(R→L Optional) |
| Driven Type | Pneumatic |
| Precision | High |
| Certification | CE |
| Condition | New |
| Nozzle | Optional |
| Air Pressure | 0.7MPa |
| Power | 220V, 1100W |
| Dimension (W*D*H) | 1000x600x1600mm |
| Weight | 500kgs |
Your inquiry about our products and price will be replied within 24 hours
We provide you with high quality materials and competitive prices
Well-trained and experienced staffs to answer your enquires in fluent English
Complete the production shipment in the shortest time
Strict QC before shipping the products,Responsible for the quality of all products
OEM & ODM services offered,Meet all your needs
|
|
