| Brand Name: | Winsmart |
| Model Number: | SMTID5X |
| MOQ: | 1 Unit |
| Price: | USD10000/Unit |
| Packaging Details: | Plywood case |
| Payment Terms: | T/T, Western Union |
High Efficiency Automatic SMT PCB Dispensing Machine For SMT PCB Assembly
SMT PCB Dispensing Machine Overview:
This unit is designed for chip sealing, PCB assembly, SMT red glue dispensing,led lens,and medical products. With adjustable track width, it can be used for dispensing of solder paste, glue, sealant, underfill, conformal coating.
SMT PCB Dispensing Machine Features:
This SMT PCB dispensing machine is using Win 10 OS and friendly software with auto alram and menu display. CCD camera system for automatic positioning correction to ensure good dispensing results. It is SMEMA interface enable the machine connect PCB loader and unloader for automation manufacturing saving cost for clients. Also, different types of dispensing valve will be used according to different application.
SMT PCB Dispensing Advantages:
1. Different dispensing valves are optional
Time-pressure valves
Pecision dispenser valves
Screw dispeser valves
Jet dispening valves
2. Spray dispensing system
3. Dots, lines, circes, free forms
4. Any dispensing heights are available.
SMT PCB Dispensing Machine Specification:
| Model | SMTID5X |
| PCB Size | 400x350mm |
| Moving Speed | 500 mm/sec |
| Conveyor Belt Speed | 200 mm/sec |
| Driven Mode | (Stepping + belt) or (servo + screw rod) |
| Program Mode | Visual CCD System |
| Repeatable Precision | ±0.02mm |
| Feeding Mode | Auto |
| Unloading Mode | Auto |
| OS | Windows 10 |
| Communication Port | SMEMA |
| Valve Quantity | 1 |
| Warranty | 1 year |
| Glue Packaging | Up to client's requirement |
| Transport height | 900±20mm |
| Transport direction | L→R(R→L Optional) |
| Driven Type | Pneumatic |
| Precision | High |
| Certification | CE |
| Condition | New |
| Nozzle | Optional |
| Air Pressure | 0.7MPa |
| Power | 220V, 1100W |
| Dimension (W*D*H) | 1000x600x1600mm |
| Weight | 500kgs |
Your inquiry about our products and price will be replied within 24 hours
We provide you with high quality materials and competitive prices
Well-trained and experienced staffs to answer your enquires in fluent English
Complete the production shipment in the shortest time
Strict QC before shipping the products,Responsible for the quality of all products
OEM & ODM services offered,Meet all your needs
|
|
