10S Cycle Cutting Time 25T PCB Separator Punching Machine for 400x400mm Boards
PCB Separator Punching Machine Features:
1. Depaneling PCBA with molds which can avoid tin cracking caused by hand folding.
2. Multiple molds are replaceable.
3. Easy to replace molds.
4. Servo push pull down mold reduces labor intensity.
5. PCB loading and unloading is easy.
6. The operation process is lightweight and safe, and the machine is equipped with safety devices.
PCB Separator Punching Machine Technical Parameters:
Driven: Hydraulic station + hydraulic cylinder
Power Supply: Phase 3, 380VAC 50HZ
Output: 25 Ton
PCB Size: 400*400MM
Working Mode: Servo motor push-pull in and out for the lower mold
Machine Dimension: 1400(L)x985(W)x1750(H)MM
Weight: 850KG
PCB Separator Punching Machine Specification:
| Working area | 400*400mm |
| Working pressure | 0.45-0.7Mpa |
| Cutting precision | ±0.05mm |
| Cycle time | 7-15 seconds |
| Output | 25T |
| PCB/FPC thickness | 0.08-3.5MM |
| PCB/FPC material | FPC, FR1, FR4, CEM-1, CEM-3, MCPCB |
| Cutting mode | Punching |
| Punch fixture | Die tooling(mold) |
| Working Property |
LCD display, Automatically records the number of processed products, automatic punching |
| Transmission port | International standard |
| Operation Language | English |
| Power | 380/220V |
| Fuse | 3A |
| Machine dimension | 1400x985x1750mm |
| Machine weight | 850kgs |
PCB Separator Punching Machine Details:
PCB Separator Punching Machine Mold Dis-assembly:
Step 1: Move lower mold to the punching location by touch screen.
Step 2: Lower the upper mold to align well with lower mold.
Step 3: Loosen 8 screws of upper mold.
Step 4: Move the whole mold to the picking location by touch screen.
Step 5: Loosen 2 screws of lower mold.
Step 6: Remove the old mold.
PCB Separator Punching Machine Mold Installation:
Step 1: Put the whole mold on the origin location.
Step 2: Lock 2 screws to fix lower mold.
Step 3: Move the whole mold into the punching location.
Step 4: Lower the upper mold base to align upper mold.
Step 5: Loosen 8 screws to fix upper mold.
Step 6: Installtion is finished.
PCB Separator Punching Machine Advantages:
1. Punching capacity is 4-8 times as PCB depaneling router.
2. Workable for all tab FPC, FR4 and MCPCB panels.
3. No dust during punching processing.
|
